THE ALLROUNDER – OUR LATEST SM5 WELDING MICROSCOPE

Only an optimal view with true safety for the operator's health leads to good welding results.

SAFETY

Unlike simple mechanical protection systems, the PUK welding microscope is equipped with a certified LCD welder's eye protection system that was specifically developed for Lampert. The eye protection system has decisive advantages for your safety.

On the one hand, the field of view is not completely darkened during welding, which results in less eye fatigue.

On the other hand, the Lampert system permanently protects your eyes from dangerous radiation (UV and IR) during welding.

Even in the event of a malfunction, the welder's eyes are still safely protected!

ERGONOMICS

Particularly with regular or long-term welding, it is extremely important for the welding microscope to feature good ergonomics.

The PUK welding microscope can be optimally set for the user and also features comfortable hand rests for relaxed and fatigue-free work.

Each welding microscope can be fitted with an optionally available head rest which makes even longer periods of work comfortable.

OPTICAL QUALITY

The lens of the PUK welding microscopes stands out where it really counts.

After 12 years of development we still remain convinced that there are two essential requirements for the lens of the welding microscope. A fixed 10x magnification and a large 20mm diameter field of view.

That means as few mechanical components or functions as possible which can be damaged by the vibrations that can occur during welding.

Here too our focus is on quality and long service life.

NEW: LED-lighting integrated in the housing of the eye protection system

NEW: The SM5 can be turned in no time at all into a workplace microscope, simply by swivelling away the hand piece arm from the field of view.

TECHNICAL DATA: WELDING MICROSCOPE

Magnification
Field of view diameter
Working distance
Dioptre adjustment
Lighting
Ergonomic hand rests
Height and angle adjustment
Weight

10 x
20 mm
145 mm
+
LED 3 W / 800 mA
+
+
3.6 kg

TECHNICAL DATA: EYE PROTECTION SYSTEM

Actively controlled LCD eye protection

system
Brightness level of the LCD

Darkness level of the LCD

Switching time
UV protection
IR protection

+
DIN 3
DIN 11
< 50 ms
> UV11
> IR11
